Multitech Control Systems provides Cold Chain Industries, Processing Industries, Ceramic Industries,
Automation System, Energy Monitoring System in Ahmedabad,Gujarat INDIA.- Economic Datalogger(2.0) - Ch (EDL-2)
The MCS-DL-2.0 data logger is a cost-effective solution for system process monitoring. It offers Universal Analog Interfaces for 8/16/32 channels with fast sampling and accurate data logs. With a 7" TFT touch screen display, users can create customized numerical and graphical views. The logger has built-in memory for up to 32,000 data points and supports data conversion to text or CSV files. It can measure and record temperatures ranging from -200 °C to +800 °C using thermocouples.
Economic Datalogger(2.0) - 4Ch EDL-2.4
Parameters Description
INPUT
UNIVERSAL -THERMOCOUPLE / RTD / MV / V / MA
NO. OF CHANNELS
4 CHANNEL
RANGE
.-100 TO 200 C /0-100 % / 0-9999 PPM
DISPLAY
7 INCH TOUCH SCREEN DISPLAY WITH HOUSING & PROGRAMMING
RESOLUTION
800*600 TFT LCD 65536 COLOURS,
ACCURACY
±0.5”, % OF FS ± 1 COUNT
DATA LOGGING RATE
10 TO 600 SECONDS PROGRAMMABLE
CONTINUOUS MONITORING
YES
INTERNAL STORAGE
UP TO 10,000 DATA FOR EACH CHANNEL (EXPANDABLE THROUGH SD CARD)
DATA LOGGING TOOL
DATA VIEWING TOOL PROVIDED FOR REPORT GENERATION
REPORT TYPE
NUMERICAL & GRAPHICAL DATA
DATA FORMAT
XLS AND PDF FILES
COMMUNICATION
1 PORT OF RS -485 AVAILABLE
ALARM OUTPUT
COMMON ALARM OUTPUT
Economic Datalogger(2.0) - 8Ch EDL-2.8
Parameters Description
INPUT
UNIVERSAL -THERMOCOUPLE / RTD / MV / V / MA
NO. OF CHANNELS
8 CHANNEL
RANGE
.-100 TO 200 C /0-100 % / 0-9999 PPM
DISPLAY
7 INCH TOUCH SCREEN DISPLAY WITH HOUSING & PROGRAMMING
RESOLUTION
800*600 TFT LCD 65536 COLOURS,
ACCURACY
±0.5”, % OF FS ± 1 COUNT
DATA LOGGING RATE
10 TO 600 SECONDS PROGRAMMABLE
CONTINUOUS MONITORING
YES
INTERNAL STORAGE
UP TO 10,000 DATA FOR EACH CHANNEL (EXPANDABLE THROUGH SD CARD)
DATA LOGGING TOOL
DATA VIEWING TOOL PROVIDED FOR REPORT GENERATION
REPORT TYPE
NUMERICAL & GRAPHICAL DATA
DATA FORMAT
XLS AND PDF FILES
COMMUNICATION
1 PORT OF RS -485 AVAILABLE
ALARM OUTPUT
COMMON ALARM OUTPUT
Economic Datalogger(2.0) - 16Ch EDL-2.16
Parameters Description
INPUT
UNIVERSAL -THERMOCOUPLE / RTD / MV / V / MA
NO. OF CHANNELS
16 CHANNEL
RANGE
.-100 TO 200 C /0-100 % / 0-9999 PPM
DISPLAY
7 INCH TOUCH SCREEN DISPLAY WITH HOUSING & PROGRAMMING
RESOLUTION
800*600 TFT LCD 65536 COLOURS,
ACCURACY
±0.5”, % OF FS ± 1 COUNT
DATA LOGGING RATE
10 TO 600 SECONDS PROGRAMMABLE
CONTINUOUS MONITORING
YES
INTERNAL STORAGE
UP TO 10,000 DATA FOR EACH CHANNEL (EXPANDABLE THROUGH SD CARD)
DATA LOGGING TOOL
DATA VIEWING TOOL PROVIDED FOR REPORT GENERATION
REPORT TYPE
NUMERICAL & GRAPHICAL DATA
DATA FORMAT
XLS AND PDF FILES
COMMUNICATION
1 PORT OF RS -485 AVAILABLE
ALARM OUTPUT
COMMON ALARM OUTPUT
